Seppi Forestry & Construction - Feature logos & advantages

Everything’s under control with MINI BLADE cutting tools and the special designed cutting depth limiter. Much like the raker on a chainsaw, the limiter controls the depth of cut and helps to prevent rotor stall which ensures an easy and high-quality mulching operation.

The M-BOOST logo is found on machines with hydraulic transmission equipped with piston motors and automatic displacement adjustment. The M-BOOST technology has all the advantages of piston motors and also has the benefit of automatically varying the torque depending on the load. This results in even more efficient work, both on large and small transport vehicles. The M-BOOST motor is always adaptable!

What some people don't know is that the actual shredding work in a mulcher is performed by the counter cutters. Depending on the model and use, a numerous series of counter blades is installed in the housing, and sometimes even under the hood, always with the aim of reducing dimensions and optimising the power demand. The SEPPI M. COUNTER CUTTERS are made of hot-forged steel and are shaped in such a way as to ensure excellent shredding performance on the one hand and a very long useful life on the other.

All mulchers and tillers equipped with replaceable wear plates inside the chassis are marked with the WEARPLATE logo. The wear plates are always made of AR400 wear-resistant steel. Although the plates have a very long service life, they may need to be replaced after a certain period of time in the event of heavy-duty applications. This is quick and easy, and your machine will then be as good as new.

With the so-called skids, the sidewalls are inserted into a frame with a sandwich structure and thus reinforced. When the weight of the excavator is supported on the mulcher, the forces are transferred to the mulcher housing.

VARIO FLOW identifies engines with adjustable displacement. Thanks to the Vario-Flow technology, the engine displacement is always adapted to the available flow rate. In this way the best working result is obtained for a hydraulic mulcher. Its flexibility is a constant feature with the ability to also use the machine on other vehicles.

This logo identifies all the machines made entirely or partially of AR400 wear-resistant steel (also called HARDOX 400). AR400 is not only very wear-resistant but also has excellent levels of solidity, which in many cases provide an advantage in terms of weight reduction.

The CARBIDE logo identifies tools with tungsten carbide inserts, a very resistant hard metal for a maximum durability. As a rule, all the fixed tools have CARBIDE inserts. With this material, a service life of up to 5 times longer than traditional hammers can be achieved. A classic is the MINI DUO tool; all V-LOCK tools are also supplied in this material.

The LOW PROFILE logo refers to those machines whose construction has been designed to be as low as possible. With the MINI-BMS and BMS-F models, it is possible to position a tilting fifth wheel and a support interface while maintaining an overall height reduced to a minimum. With MINIFORST cl, however, this feature is important for the driver to have a good view of the work area.

Replaceable stub shaft on the rotor axle. Thanks to the particular way of manufacturing, the shaft becomes very reliable against impacts and stress. In the very unlikely event of damage, the shaft only is an easy replacement part.

2SPEED POWERSHIFT identifies machines equipped with an electro-hydraulic gearbox. The difference compared to the simple 2SPEED is the fact that the gearbox changes the rotation speed of the tiller directly from the ISOBUS terminal of the tractor while the machine is running. This means being able to quickly and conveniently switch from slow to fast gear and the machine can be flexibly adapted to the working conditions at any time. The drive shaft always remains at the optimum speed, i.e. 1000 rpm.

Most SEPPI M. mulchers have this feature right from the start. The logo identifies machines with tools or hammers arranged in a spiral on the rotor shaft. This results in incredibly smooth operation, as well as low energy requirements and reduced noise generation and, last but not least, an excellent work result.

In these machines, the power is not transmitted to the rotor through the usual pulleys and V-belts but through a series of gears. Compact installation space, high transmissible torques and continuous lubrication are just some of the many advantages of this technology.

Power is transmitted via special carbon fibre belts. Due to the extreme tensile strength of this material, its transmission is comparable to that of a steel chain. The carbon belt also boasts the added advantage of having almost no friction loss and requiring no lubrication. Through the latter it is possible to transmit high torques and powers of up to 500 HP.

Intelligent and efficient! This innovative tool system impresses with its perfect fit which makes it unique: it gives an outstanding stable hold and allows an easy replacement in a time and effort saving manner

The ADAM alignment system developed by Seppi M is used to optimally use the mulchers and tillers even on difficult terrain. By adjusting the angle of the transmission, the corresponding device is able to lift much higher and to drop much lower than normal. In all other situations, ADAM helps maintain an optimal drive shaft angle and thus protects the entire kinematic chain.

The DUAL logo on the BMS-L model indicates that the machine is built symmetrically and has two hoods, both of which can be opened. This allows the user to flexibly adapt their machine to the working conditions.

SEPPI now applies an ISOBUS control system as standard on many of these machines! On ISOBUS-compatible tractors, the ISOBUS socket of the mulcher is connected to the tractor and some functions are controlled or monitored directly on the on-board computer in the tractor or excavator cab.

2SPEED identifies those machines equipped with a manual gearbox. The gearbox is used to manually change the speed directly on the tiller or mulcher, to work at a slow or fast speed. The drive shaft always runs at the optimum speed, which is 1000 rpm.

With the PLUG & PLAY hydraulic motors, the mulcher can be easily connected to the excavator without having to first measure and adjust the flow rate to the excavator. Preparing the machine for work has never been easier.

The FLOAT floating device allows the mulcher to oscillate so that it can freely follow the contour of the ground. With just one bolt, the floating device can be locked at any time if conditions so require.

This logo designates our hydraulically-operated products, equipped with a highly efficient piston motor. Our accessories, recognisable with this logo, work with maximum performance and high efficiency. They are therefore suitable for the most demanding applications.

This logo demotes high grip tracks for working on steep ground.

Self tensioning tracks. The individual tracks are tensioned by a hydraulic system, which regulates the tension according to the conditions of the ground and prevents the track from slipping or breaking.
